Model 3/3 Highland 18"-20" Two-Piece Forged Wheels | Tlyard® TLS-01

Redefine your Tesla’s visual impact with the Tlyard® TLS-01, a high-performance two-piece forged wheel inspired by the aggressive, exotic aesthetics of the SF90 Spider. Specifically engineered for both the classic Model 3 and Model 3 Highland, this wheel bridges the gap between daily efficiency and supercar styling.

Technical Specifications

Series Name	Tlyard® TLS-01
Construction	Two-Piece Forged
Material	6061-T6 Aerospace Aluminum Alloy
Vehicle Fitment	Tesla Model 3 & Model 3 Highland (All Variants)
Wheel Diameter	18″ / 19″ / 20″ (Customizable)
PCD (Bolt Pattern)	5×114.3
Center Bore (CB)	64.1 mm
Lug Nut Spec	M14×1.5
Finish Options	Gloss Black/Satin Gunmetal/Antique Bronze(Customizable)
Load Rating	900 kg/1984 lbs per wheel (Safety Certified)



Exotic SF90-Inspired Design
Brings the soul of an Italian supercar to your Tesla, featuring ultra-slim, aerodynamic spokes that create a striking and aggressive profile.

Advanced Two-Piece Forged Construction
Features a modular design with a separate rim and center disk, providing a more complex, multi-dimensional look compared to standard monoblock wheels.

Bespoke Multi-Tone Finishes
The two-piece assembly allows for unique color combinations, such as a Gloss Black barrel paired with a Satin Gray face, for a truly customized aesthetic.

Performance & Efficiency Driven
The lightweight forged design minimizes rotational mass, helping to maintain your Tesla's range (Wh/mi) while improving acceleration and braking response.

Seamless OEM Compatibility
Designed to work perfectly with original Tesla TPMS sensors and factory lug nuts, supporting a clean, factory-plus installation.

Detailed Size & Weight Matrix

Size	Width & Offset	Tire Recommendation	Estimated Weight (per piece)
18"	18x8.5" ET+35	235/45-18	~11.5 kg (25.4 lbs)
19"	19x8.5" ET+35	235/40-19	~12.75 kg (28.1 lbs)
20"	20x9.0" ET+35	235/35-20	~13.5 kg (29.8 lbs)



Frequently Asked Questions (FAQ)

Q1: What are the shipping options and delivery times?

Shipping Method & Cost	Destination	Estimated Time
Standard Sea Shipping (FREE)	Global	Approximately 30-35 days
Expedited Air Freight ($500 USD)	Global	Approximately 15 days after production is complete



Q2: How long does the custom production take?

Each Tlyard Forged wheel is custom-forged and precision CNC-machined to your exact specifications.The standard production lead time is approximately 30 days.

Q3: How much weight will I save by upgrading to Tlyard Forged wheels?

• For the same size and style, forged wheels are typically about 10%–25% lighter than cast wheels.

Q4: Are forged wheels stronger than the original factory wheels?

• Yes, forged wheels offer superior durability.
• While most factory wheels are cast for mass production, our forging process creates a much denser and more refined metal structure.
• This results in significantly higher structural strength and impact resistance.

Q5: Do I need to buy new tires?

• If you choose the same diameter as your original wheels (e.g., 19" to 19"), you can reuse your existing tires.
• If you upgrade to a larger diameter (e.g., upgrading from 19" to 20" or 21"), you will need to purchase new tires matching the updated specifications.

Q6: Can I customize the style, size, or color?

• Absolutely, we offer comprehensive customization services.
• Our professional team[[email protected]] will work closely with you to ensure the final product matches your exact preferences for your Tesla.
